Case Study
A global chemicals major operating 12+ plant sites across North America required a scalable, automated data ingestion platform to unify operational, engineering, and enterprise data into Cognite Data Fusion (CDF). Data was scattered across SAP PM/MM, IP21 time-series historians, GOS, SPF, and engineering document systems — with no repeatable framework for deploying and managing data pipelines across multiple environments.
Infosys built a Databricks-powered data engineering platform using Databricks Asset Bundles (DAB) — an infrastructure-as-code approach that defines 150+ automated scheduled workflows as YAML code, deployed consistently to dev, staging, and prod via Azure DevOps CI/CD pipelines.
Unity Catalog with Delta Lake serves as the governed, three-tier data layer (DEV / PROD) decoupling source extraction from CDF ingestion. Per-site transformation notebooks (tr_* naming convention) use state-based incremental loading to process only changed records — minimizing compute cost and maximizing data freshness.
The result: every pipeline is version-controlled, environment-safe, and reproducible. The platform covers 12+ plant sites with a single unified codebase and delivers trusted operational intelligence to field workers, operations teams, and engineers across the organization.
150+
Automated Databricks workflows deployed as code
12+
Plant sites with active data pipelines
5+
Source system types integrated (SAP, IP21, GOS, SPF, Docs)
2
Environments managed (DEV / PROD) from a single codebase
Key Challenges
- Siloed engineering, operational, and IT data across systems.
- Multiple disparate enterprise and operational data sources.
- Lack of contextualized relationships between business data assets.
- Limited access to trusted operational information.
- Difficulty generating insights from disconnected data environments.
- Need for enterprise-wide operational visibility.
- Requirement for scalable data foundation supporting AI initiatives.
Ready to experience?
Talk To Experts
Infosys Approach
Adopted Databricks Asset Bundles (DAB) as the infrastructure-as-code framework for all Databricks Workflow definitions.
Defined 150+ Databricks Jobs as YAML files in a resources/ folder, each parameterized with ${var.*} variables for environment switching.
Established dev, staging, and prod targets in databricks.yml — a single YAML controls workspace host, repo path, catalog, and schedule pause state per environment.
Leveraged Unity Catalog with Delta Lake as a three-tier governed data layer (DEV /PROD) decoupling source ingestion from CDF loading.
Implemented state-based incremental loading using watermark tables — only new or changed records processed per run, with a forceFullLoad widget for full reloads.
Standardized per-site, per-data-type transformation notebooks (tr_* naming convention) covering assets, work orders, notifications, functional locations, and time-series.
Automated CI/CD deployment via Azure DevOps: databricks bundle validates on PR, databricks bundle deploys to target on merge.
Provisioned per-job ephemeral single-node clusters (Standard_F8s) — compute spins up on demand and terminates after each run, minimizing idle cost.
Created cross-site Manufacturing Hub aggregation notebooks producing unified Delta tables for enterprise-wide analytics and Power BI dashboards.
The Solution
Databricks Asset Bundles delivering governed, automated, and reproducible data pipelines at scale.
- Databricks Asset Bundle (DAB) framework: 150+ workflow jobs as YAML code — ${var.*} substitution makes the same definition run identically in dev and prod.
- Unity Catalog three-tier Delta Lake (DEV /PROD): source data lands in Delta tables; transformation notebooks read from the governed source catalog and write to the output catalog.
- Per-site transformation notebooks (tr_* convention): one notebook per site × data type — assets, work orders, notifications, functional locations, process tags.
- State-based incremental loading with watermark tracking: only new/changed records processed per run; forceFullLoad widget enables complete refresh on demand.
- Azure DevOps CI/CD pipeline: bundle validate on every PR; bundle deploy on merge — no pipeline change reaches production without code review and validation.
- Ephemeral single-node job clusters (Standard_F8s, Spark 17.3): spin up per run, shut down on completion — no idle compute cost.
- Azure Key Vault secret scope: service principal credentials fetched at runtime via dbutils.secrets.get — zero hardcoded credentials in any notebook.
- Manufacturing Hub aggregation layer: cross-site unified Delta tables powering enterprise KPI dashboards in Power BI.
- Enabled trusted operational intelligence, advanced analytics, and future Generative AI initiatives on the CDF knowledge graph.
Business Outcomes
150+ automated Databricks workflows deployed as version-controlled YAML code — zero manual deployment steps.
Data pipelines running across 12+ plant sites on a single unified Databricks platform.
Environment-safe deployments: CI/CD pipeline validates every change before reaching production.
State-based incremental loading reduced redundant data processing, cutting compute costs and improving data freshness.
New site onboarding accelerated — adding a site requires one YAML workflow definition and one tr_* notebook, no infrastructure changes.
Established a governed, scalable data foundation enabling advanced analytics, AI use cases, and future Generative AI applications on CDF.
Benefits
Scalable, code-driven data pipelines delivering trusted operational data to every plant site.
Infrastructure as code: every pipeline defined, versioned, peer-reviewed, and deployed through Git and Azure DevOps.
Environment consistency: identical codebase in dev and prod — ${var.*} variable substitution eliminates environment drift.
Cost-efficient compute: ephemeral job clusters spin up on demand and terminate after each run — no idle costs.
Operational data freshness: incremental watermark loading ensures near-real-time data in CDF without expensive full reloads.
Scalable site expansion: onboarding a new plant site requires only a new YAML workflow and a tr_* notebook — no infrastructure redesign.
Security by design: Azure Key Vault secret scopes eliminate hardcoded credentials across every notebook.
Foundation for AI: governed Delta Lake + CDF knowledge graph ready for advanced analytics and Generative AI applications.
